A&B Eagleline CHH-CO Disc Harrow – 20-Inch Cut-Out Blades, 8’2″–11’4″ Width, 45–70 HP Tractor Use

Description

Product Description

A & B Eagleline Equipment | 3-Point Clevis Hitch Disc Harrow W/ 20″ Cut-Out Blades | Model CHH-CO Series | Width 8’2″ to 11’4″ | Horsepower 45-70 HP | For Tractors

DESCRIPTION

The A & B Eagleline Clevis Hitch Disc Harrow series is the ideal solution for those seeking high-efficiency tillage tools to prepare soil for planting. Available in widths from 8′-2″ to 11′-4″, these heavy-duty harrows come with 20″ Cut-Out Blades, ensuring excellent soil disruption and seedbed preparation across a variety of soil types. Built with regreaseable bearings, these harrows are easy to maintain and designed for extended durability, providing consistent performance throughout their long operational life.

With recommended tractor horsepower ranging from 45 HP to 70 HP, these harrows offer unmatched versatility, catering to everything from smaller to larger farm operations. Whether you’re managing a compact farm or a larger acreage, the A & B Eagleline Clevis Hitch Disc Harrow ensures that your land is properly prepared for planting, with reduced soil compaction and uniform tillage.

Key Features

• High-Quality 20″ Cut-Out Blades: Provides aggressive soil penetration to break up tough soil and create a fine seedbed.
• Regreaseable Bearings: Low-maintenance design that extends the life of your harrow and reduces downtime.
• Multiple Widths Available: Choose from 8′-2″ to 11′-4″, depending on your field size and tillage needs.
• Variable HP Compatibility: Suitable for tractors ranging from 45 HP to 70 HP, ensuring compatibility with various equipment.
• Durable Construction: Built to withstand demanding soil conditions and heavy-duty agricultural tasks, ensuring long-term reliability.
• Even Tillage with Consistent Results: Blade spacing options range from 8″ to 9″, offering uniform soil disturbance for improved soil health.

Detailed Specifications

Specification	CHH202099-CO (8′-2″)	CHH242088-CO (8′-8″)	CHH242099-CO (9′-8″)
Working Width	8′-2″	8′-8″	9′-8″
Number of Discs	20	24	24
Disc Size	20″ Cut-Out	20″ Cut-Out	20″ Cut-Out
Spacing Between Discs	9″	8″	9″
Recommended Tractor HP	45-65 HP	45-55 HP	50-60 HP
Weight	1,217 lbs	1,249 lbs	1,403 lbs
Bearings	Regreaseable	Regreaseable	Regreaseable
Material	High-Strength Steel	High-Strength Steel	High-Strength Steel



Specification	CHH282088-CO (10′)	CHH282099-CO (11′-3″)	CHH282100-CO (11′-4″)
Working Width	10′	11′-3″	11′-4″
Number of Discs	28	28	32
Disc Size	20″ Cut-Out	20″ Cut-Out	20″ Cut-Out
Spacing Between Discs	8″	9″	10″
Recommended Tractor HP	50-60 HP	55-65 HP	60-70 HP
Weight	1,372 lbs	1,472 lbs	1,515 lbs
Bearings	Regreaseable	Regreaseable	Regreaseable
Material	High-Strength Steel	High-Strength Steel	High-Strength Steel



Manuals & Documents

HARROWS BROCHURE

General Warranty Info:

• Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
• The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
• Expendable components and “wear parts” including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
• Please reach out to us for any specific warranty information needed about products and parts you can’t find!

Videos

Shipping

General Shipping Info:

• Instantly calculate shipping quotes to the lower 48 states by 1. adding this product to your cart, 2. click continue to the checkout page and 3. enter your shipping address to check rates. Contact us for quotes for shipping to Hawaii, Alaska, Canada, Mexico and Internationally.
• Complimentary lift gate service on all freight shipments where it’s possible. We guarantee safe delivery!
• Low shipping rates for customers. We have negotiated the best possible rates for customers from our trusted carriers (ODFL, ESTES, UPS, and FedEx).
• Negotiate shipping rates if you think we can do better please reach out. Keep in mind some shipping rates also include assemble & configuration that as well!
