Albin Group 280 Series Flange-Mount Marine Air Blower — 12V DC [10-02-001]

Description

Marine Air Blower 280 Flange – 12V

3″ flange mounted marine ventilation 12V radial blower with capacity 280 m3 per h, 163 CFM. Inlet 72mm, outlet 72mm.

Body in hermoplastic PA6 high durable white Nylon with integrated blower motor. 3,8A fuse.

Interchangeable with Jabsco 34739-0010, Johnson Pump 80-47416-01.

Features:

• Weight: 0.88 kg/1.5 lbs
• Dimensions: 200/7.87L x 165/6.6H x 195/7.7W mm/in
• 3″ Flange
• CE marked ISO 9097:1991 Marine (small craft electrical fans), ISO8846 1990 (ignition protection), ISO 10133 2000 (electrical systems), EN55014-1 2006 (2004/108EC)

Specifications:

• Ducting: 3″
• Open Flow (CFM): 163 CFM
• Volts: 12v
• Box Dimensions: 8″H x 8″W x 8″L WT: 2.5 lbs
• UPC: 7340176602404
