Fleming TR14 Monocoque Tipping Trailer – 14-Ton Capacity, 95″ Width, Designed for Tractors and Loaders (40–60 HP, 25–60 GPM)

Description

Product Description

Fleming 14-Ton Monocoque Tipping Trailer | Model TR14 | Width 95″ | 25-60 GPM | 40-60 HP | For Tractors & Loaders

DESCRIPTION

The Fleming 14 Ton Monocoque Tipping Trailer (TR14) is engineered for the demands of modern farming operations, combining strength and efficiency in one heavy-duty package. Featuring a high-tensile steel monocoque body, this trailer is built to handle the heaviest loads while reducing weight for increased payload. Whether you’re hauling grain, silage, muck, or other materials, the TR14 ensures smooth and fast unloading with its twin hydraulic tipping rams and tapered body design. With Hydraulic Flow: 25-60 GPM and Horsepower: 40-60 HP, it pairs perfectly with tractors and loaders, providing the power and versatility you need for any task. The trailer’s sprung drawbar and multi-leaf spring suspension reduce strain on your towing vehicle and operator, ensuring comfort and durability. Built for reliability, the TR14 is a must-have tool for any agricultural professional.

Key Features

• Monocoque body design offers unmatched strength and reduces weight for optimal payload capacity.
• Tapered body and hydraulic tipping rams ensure fast, efficient, and clean unloading every time.
• Sprung drawbar with multi-leaf suspension minimizes stress on both the towing vehicle and the operator.
• Heavy-duty 5mm floor designed to withstand the toughest hauling conditions.
• Hydraulic hoses securely concealed within the chassis for enhanced safety and longevity.
• 10-stud commercial axle for increased durability and long-term performance.
• 550/45/22.5 flotation tyres for superior traction and stability, even on soft or uneven ground.
• 40mm EN8 towing eye ensures secure connections for reliable towing across all types of terrain.
• Hydraulic hose carrier for organized and easy hose management.
• Built-in access ladder for effortless access to the trailer during loading or maintenance.
• LED lights standard for safe operation in low visibility or night-time conditions.
• Optional hydraulic back door with locking safety valve to prevent accidental spillage.
• Galvanised silage extension kit with automatic trip and swinging back door for easy unloading.
• Grain chute option allows for faster, cleaner unloading of grain and other bulk materials.
• Air brakes with load-sensing valve for enhanced control and braking safety when hauling heavy loads.
• Hydraulic Flow: 25-60 GPM, and Horsepower: 40-60 HP required for optimal trailer operation with your tractor or loader.

Detailed Specifications

Specification	Details
Model	TR14
Body Length	18′ 8″ (5700mm)
Width	7′ 11″ (2400mm)
Floor Thickness	5mm
Side Height	51″ (1300mm)
Unladen Weight	9,524lbs (4660kg)
Capacity	14 Ton (16.48m³)
Loading Height	48″ (1220mm)
Towing Eye	40mm EN8
Wheel Size (Standard)	550/45/22.5
Optional Wheel Size	385/65/22.5
Brake Size	127DIA, BR 420×180
Side Height with Silage Kit	11′ (3380mm)
Unladen Weight with Silage Kit	11,240lbs (5100kg)
Air Brakes (Optional)	Yes
Hydraulic Flow	25-60 GPM
Horsepower Requirement	40-60 HP
