Guardian HED722517 Hydraulic Leveler | 72″ Width | 25,000 lb | Refrigerated Trailer Dock Compatibility

Description

Product Description

Guardian Industrial Products Hydraulic Edge of Dock Leveler | Model HED722517 | 72″ W | 25,000 lb Capacity | For Refrigerated Trailer Dock

DESCRIPTION

Designed for fast-paced loading docks that demand safety, strength, and reliability, the Guardian 72″ Hydraulic Edge of Dock Leveler delivers a smarter alternative to traditional dock boards. Built in the USA from heavy-duty structural steel, this hydraulic dock leveler permanently mounts to your dock edge, creating a seamless bridge between the dock and refrigerated trailers.

Engineered specifically for cold-storage and refrigerated trailer applications, this model features dual dock bumpers, a hydraulic power pack, and solid-state controls that allow smooth, quiet, one-person operation. With a 25,000 lb capacity, it easily supports forklifts, pallet jacks, and heavy material handling equipment throughout demanding shifts.

The automatic return-to-stored position activates immediately when the trailer pulls away, enhancing safety while reducing downtime. A 5″ operating range above and below dock level, combined with a 12.75″ lip projection, ensures reliable trailer engagement even with height variances. Built to meet or exceed OSHA and ANSI standards, this edge of dock leveler is a long-term solution for warehouses seeking efficiency, durability, and peace of mind.

Key Features

• Heavy-Duty Steel Construction Manufactured in the USA using high-yield tread plate steel to withstand continuous forklift traffic and harsh loading dock environments.
• 25,000 lb Load Capacity Easily supports forklifts, pallet jacks, and heavy cargo, making it ideal for high-volume refrigerated warehouse operations.
• Hydraulic Edge-of-Dock Design Installs directly to the dock face, eliminating the manual handling and safety risks associated with portable dock boards.
• Optimized for Refrigerated Trailers Engineered specifically for cold-storage docks where consistent trailer positioning and sealing are critical.
• Automatic Return Safety System Leveler automatically lowers to the stored position when the trailer departs, reducing fall hazards and dock damage.
• 5″ Vertical Operating Range Accommodates trailers positioned up to 5 inches above or below dock height for consistent loading alignment.
• 12.75″ Lip Projection Provides secure contact with trailer beds while maintaining proper weight distribution during loading and unloading.
• Solid-State Hydraulic Controls Ensures smooth, quiet, and dependable operation with reduced maintenance and improved system longevity.
• Two-Cylinder Hydraulic System Delivers stable lifting and lowering performance for controlled, shock-free dock transitions.
• Integrated Dock Bumpers Dual molded rubber bumpers protect both the dock face and leveler from repeated trailer impact.
• Enclosed Industrial Power Pack Features a fully enclosed electric motor and hydraulic pump rated up to 4,000 PSI for reliable performance.
• Continuous Greaseable Lip Hinge Extends service life by reducing wear and ensuring smooth articulation under heavy loads.
• Forklift-Friendly Installation Designed with centerplate hinges and steel rivets for fast, efficient forklift-assisted installation.
• OSHA & ANSI Compliant Design Meets or exceeds CS202-56, OSHA, and ANSI MH14.1 safety and performance requirements.
• Low-Profile Stored Position Reinforced with formed steel gussets to provide structural support and minimize dock obstruction when not in use.

Detailed Specifications

Specification	Details
Brand	Guardian Industrial Products
Model Number	HED722517
Dock Leveler Type	Hydraulic Edge of Dock
Width	72 inches
Maximum Capacity	25,000 lbs
Operating Range	5 inches above & below dock
Lip Projection	12.75 inches
Overall Span	27.75 inches
Material	High-Yield Steel Tread Plate
Hydraulic System	4,000 PSI Electric Power Pack
Control Type	Solid-State Rotary Switch
Bumpers Included	Two Molded Rubber Dock Bumpers
Compliance	OSHA, ANSI MH14.1
Country of Origin	Made in the USA
Primary Compatibility	Refrigerated Trailer Loading Docks
