Kinedyne Grade 70 Grab Hook Chain Assembly – 3/8″ x 16 ft, 3,000 kg WLL, 25 Units/Barrel for Cargo & Industrial Tie-Downs

Description

Product Description

Kinedyne Grade 70 Grab Hook Chain Assembly | Width 3/8″ | Length 16′ | Working Load Limit 3,000 Kg | 25 Units Per Barrel | For Cargo & Industrial Tie-Down Applications

DESCRIPTION

The Kinedyne 3/8″ x 16′ Grade 70 Grab Hook Chain Assembly is engineered for heavy-duty cargo securement, offering superior strength and durability. Manufactured from heat-treated carbon steel with a gold dichromate zinc-plated finish, this chain assembly provides a Working Load Limit (WLL) of 6,600 lbs (3,000 kg) and a Breaking Strength of 26,400 lbs (11,975 kg).

Each assembly comes pre-cut at 16 feet and is equipped with forged alloy steel Clevis Grab Hooks, designed with a narrow throat for secure, no-slip handling. Packaged in a reusable steel barrel with 25 units per barrel, these assemblies are ready to use immediately, saving time and effort for fleets, flatbed operators, and industrial users.

Compliant with National Association of Chain Manufacturers (NACM) standards, each chain is embossed with the manufacturer’s identification mark and the grade designation “70.”

⚠️ Note: Not intended for overhead lifting.

Key Features

• Material: Heat-treated carbon steel construction
• Size: 3/8-inch diameter, 16-foot length
• Working Load Limit: 6,600 lbs / 3,000 kg
• Breaking Strength: 26,400 lbs / 11,975 kg
• Hooks: Forged alloy steel Clevis Grab Hooks
• Weight: 618 lbs / 280 kg per barrel (25 units)
• Finish: Gold dichromate zinc-plated coating
• Identification: Embossed with Grade 70 marking
• Compliance: Meets NACM manufacturing standards
• Packaging: 25 chain assemblies per steel barrel
• Applications: Transport, cargo securement, industrial use
• Restrictions: Not for overhead lifting

Detailed Specifications

Specification	Details
Brand	Kinedyne
Model	3/8″ x 16′ Grade 70 Grab Hook Chain Assembly
Product Code	10038-16BRL
UPC Code	52474007863
Type	Transport Chain Assembly
Material	Heat-Treated Carbon Steel, Zinc Plated
Chain Grade	70
Diameter	3/8 inch (0.3 inches width)
Length	16 feet per assembly
Working Load Limit (WLL)	6,600 lbs / 3,000 kg
Breaking Strength	26,400 lbs / 11,975 kg
Hooks	Forged Alloy Steel Clevis Grab Hooks
Hooks WLL	6,600 lbs / 3,000 kg
Hooks Breaking Strength	26,400 lbs / 11,975 kg
Hooks Finish	Zinc Plated, Gold Dichromate
Hooks Color	Gold Dichromate
Barrel Weight	618 lbs / 280 kg (25 assemblies)
Packaging	Steel Barrel, 25 Units
Compliance	NACM Recommendations
Identification	Embossed with Manufacturer’s ID & Grade “70”
Applications	Cargo Securement, Transport, Industrial, Commercial Projects
Restrictions	Not for Overhead Lifting
Welded Chain	True
Finish	Zinc Plated, Gold Dichromate Color
Country of Origin	China
Shipping Days	3–5
Proposition 65	No
Specification Met	NACM – National Association of Chain Manufacturers
