Sveaverken F100G GPS Guidance System – 10″ Touchscreen, 9–36 V Operation, Precision Farming Navigation for 100–500 HP Tractors

Description

How To Request A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Sveaverken | F100G Guidance System | 10” Touchscreen | 9 To 36V Operating Voltage | 10″ Display | Precision Farming GPS Navigation | Horsepower 100 To 500 HP | For Tractor

DESCRIPTION

Step into the future of agriculture with the Sveaverken F100G Guidance System, your gateway to precision farming without the steep learning curve. Designed specifically for tractors between 100 To 500 HP, this intelligent GPS-based navigation tool delivers high-accuracy guidance in every pass whether you’re planting, spraying, tilling, or harvesting.

Forget the stress of overlapping rows, missed spots, and wasted inputs. The F100G helps operators of all skill levels navigate fields with ease, delivering pinpoint accuracy even in long workdays, poor visibility, or rugged terrain. By reducing fatigue and maximizing field coverage, it boosts productivity, minimizes waste, and brings you closer to a more sustainable, profitable farm.

Whether you’re just getting started with smart farming or looking to optimize every inch of your land, the Sveaverken F100G is the trusted co-pilot you didn’t know you needed.

Key Features

• High-Precision GNSS Navigation Supports multiple satellite correction services (GPS, GLONASS, Galileo, BDS) for precise, real-time guidance in any condition.
• User-Friendly 10” Touchscreen Bright, responsive display allows for quick setup, navigation, and real-time course corrections.
• Wireless GNSS Connection No more complicated wiring from roof to cabin enjoy seamless setup with built-in WiFi connectivity.
• Compatible with tractors ranging from 100 To 500 horsepower, making it ideal for both medium and large-scale farming operations.
• Smart Path Planning Choose the optimal guidance line type based on task and field shape to improve efficiency and reduce fuel use.
• Real-Time Course Correction Live feedback and alerts help you stay precisely aligned, even on uneven or sloped fields.
• Historical Field Data Management Save guidance lines, task records, and boundary maps for smarter planning season after season.
• Guidance Line Translation & Scaling Easily shift or adjust guidance lines without re-mapping perfect for changing field needs.
• Flexible GNSS Corrections Achieve sub-inch accuracy by selecting the right correction service for your location and task.
• Durable & Rugged Build With IP65/IP67-rated protection, the F100G withstands dust, water, and extreme temperatures.
• Effortless Installation Simplified setup process helps you go from box to field in under an hour.
• Energy Efficient Design Operates between 9 To 36V, suitable for a wide range of modern and older tractors.
• Scalable System Easily upgrade to F100 model with automatic steering and advanced features when you’re ready.
• Future-Proof Compatibility ISOBUS and Farm Management System integration planned for future enhancements.
• Stay Focused Longer Reduces operator fatigue by automating alignment, freeing you to focus on overall field operations.
• Eco-Conscious Efficiency Reduce overlap, conserve fuel, and lower input waste for a greener, more profitable farm.

Detailed Specifications

Category	Details
Brand	Sveaverken
Model	F100G
Function	GNSS-Based Tractor Guidance System
Display	10″ IPS Touchscreen, 1280×800 Resolution
Compatibility	Tractors (100 To 500 HP)
Operating Voltage	9 To 36V
Control Terminal Size	211.5 mm × 136.0 mm × 16.3 mm
GNSS Receiver Size	162 mm × 78 mm
GNSS Support	GPS L1/L2/L5, GLONASS L1/L2, Galileo E1/E5, BDS B1/B2/B3, SBAS
Correction Services	Supports multiple GNSS correction formats
Wireless Connectivity	WiFi-enabled communication between terminal and receiver
Storage Temperature	Terminal: -40 To 70°C; GNSS Receiver: -40 To 85°C
Operation Temperature	Terminal: -20 To 55°C; GNSS Receiver: -20 To 70°C
Terminal Protection	IP65 Dust & Water Resistant
Receiver Protection	IP67 Fully Sealed for Harsh Environments
Steering Support	Manual Guidance Only (Upgradeable to F100 for Auto-Steer)
Field Data Storage	Field Boundaries, Guidance Lines, Task History
Software Compatibility	Planning Tool Compatible; ISOBUS Integration Planned
Line Adjustment Tools	Translation, Scaling, Sync
