TAG Compact Bellhole & Grave Bucket: 36″ Width for 1.25–2 Ton Excavators

Description

Product Description

TAG Bellhole / Grave Bucket | Width 36″ | Machine Size 1.25–2 Ton | For Excavators

DESCRIPTION

The TAG Bellhole / Grave Buckets are engineered to deliver straight-sided, cleanly cut holes for precise vault and casket placement—ideal for grave preparation, utility burial, and narrow trenching. Designed for compact excavators in the 1.25–2 ton weight class (approx. 2,500–4,000 lbs), these buckets are available in multiple mounting styles to accommodate a range of machines.

Crafted for professional cemetery contractors and utility specialists, these buckets combine low-profile dimensions with rugged steel construction for reliable performance in restricted-access environments.

Key Feature

• Straight-Walled Excavation Ideal for vaults, caskets, and burial boxes; limits ground collapse.
• Mount Style Variety Supports OEM pin-on, wedge lock (Deere/Hitachi), Kubota USA, and hook-style T-pin configurations.
• Excavator Class Compatibility Suits compact machines ranging from 1.25–2 tons (2,500–4,000 lbs).
• Precision Bucket Sizing Bucket widths from 36″, capacity ranges from 0.093–0.140 cubic yards.
• Heavy-Duty Steel Construction Designed to handle frequent, repetitive dig cycles in cemetery and trenching operations.

Detailed Specifications

Mount Style	Order #	Bucket Width
OEM Pin-On	3609MX2	36″
Kubota USA	3609MX2-KUB	36″
Wedge Lock (JD/Hitachi)	3609WL2-JD	36″

Host Machine Compatibility

MAKE	MODEL 2500 – 6000 LBS.
BOBCAT	E20, E16, E14, 323, 325, 328
CASE	CX14, CX17B
CAT	301.5, 301.6, 301.8 301.6C, 301.8C
DEERE	17G, 17D, 17C
DOOSAN	SOLAR015
GEHL	143, 153, 193, 223, 253, EC17, 192
HITACHI
HYUNDAI	R15-7, R16-7, R22-7
IHI / KATO	17VXE, 15VX, 15NX, 10G, 12G, 14G, 15J
JCB
KOBELCO	13SR, SK13SR, SK15SR
KOMATSU	PC18Mr-2, PC20Mr-2 PC15R-8, PC15Mrx
KUBOTA	B20, B21, U15, KX41-3
MUSTANG	1403, 1503, 1903, 2203, 2503, 1902
TAKEUCHI	TB216, TB016, TB014
TEREX	HR1.5/TC15, HR1.6/TC16 HR2.0/TC20
THOMAS
VOLVO	EC15B, EC20B
WACKER	1404, 2503
YANMAR	VIO15-2, VIO17, VIO20-2 VIO15-3, VIO20-3, B15

Mountings

STYLE	PHOTO
OEM PIN ON – All excavators can use this set up by removing the coupler. Multi pin and pin grabber couplers also use this mounting
WEDGE LOCK – John Deere and Hitachi use this system in the USA. You also see this type of coupler in Canada.
KUBOTA USA – Kubota uses this coupler type in the USA. They are machine specific. Canada Kubota couplers are typically different.
Quick Coupler – Wain Roy style hook and pin 1.25″ vertical pin design (QC27) SOLD ON ANOTHER PAGE
BOBCAT EXCHANGE – Bobcat uses this coupler system from the factory. TAG DOES NOT MAKE THIS COUPLER SYSTEM
