TAG ITA-Style Pallet Forks: 48″–72″ Tines for 5–8 Ton Wheel Loaders & Backhoes

Description

Product Description

TAG ITA Style Pallet Fork | Tine Length 48″-72″ | Machine Size 5–8 Ton | For Wheel Loaders & Backhoes

DESCRIPTION

The TAG ITA Style Pallet Fork Series offers a rugged, medium-duty solution for contractors, site managers, and yard operators using rubber-tire wheel loaders and backhoes. Built around the traditional notched backboard design, these forks maintain high visibility, durability, and compatibility across a wide range of loader and backhoe platforms.

Available in ITA Classes 2 through 4, each model is crafted with heavy-gauge steel forks, precision-carriage construction, and adjustable spacing for versatile jobsite handling. Optional top guard/rack available for added load retention—contact TAG or LEC for details and lead times. Refer to the “FITS” tab for make/model compatibility.

Key Features

• Heavy-Duty ITA Style Tines Forged fork blades with high strength-to-weight ratios—ideal for pallets, pipe, timber, and bulk loads.
• Traditional Notched Backboard Design Delivers reliable load positioning and operator visibility across varied applications.
• Quick Coupler Compatibility Designed to integrate with pin-on and quick coupler setups for efficient mount/dismount cycles.
• Multiple ITA Classes & Capacities Covers Classes 2–4, with ratings from 6,400 lbs up to 33,250 lbs for both compact and heavy machinery.
• Optional Top Guard/Rack Add-on available for better containment of taller or unstable loads—ask TAG for pricing and install options.
• Carriage Widths and Tine Lengths Available from 48″ to 96″ widths and 48″ to 72″ tine lengths to match machine specs and jobsite needs.

Detailed Specifications

Class 2

SKU #	QC100UPF4848
Rated Capacity	6,400 lbs
Carriage Width	48″
Tine Cross Section	1.75″ × 4″
Tine Length	48″
Between Forks	48″
Fork Height	26″
Weight	750 lbs

SKU #	QC100UPF4860
Rated Capacity	6,400 lbs
Carriage Width	48″
Tine Cross Section	1.75″ × 4″
Tine Length	60″
Between Forks	48″
Fork Height	26″
Weight	790 lbs

Class 3

SKU #	QC300UPF6048
Rated Capacity	10,500 lbs
Carriage Width	60″
Tine Cross Section	2″ × 5″
Tine Length	48″
Between Forks	60″
Fork Height	26″
Weight	880 lbs

SKU #	QC300UPF6060
Rated Capacity	10,500 lbs
Carriage Width	60″
Tine Cross Section	2″ × 5″
Tine Length	60″
Between Forks	60″
Fork Height	26″
Weight	950 lbs

SKU #	QC500UPF9672
Rated Capacity	19,700 lbs
Carriage Width	96″
Tine Cross Section	2.5″ × 6″
Tine Length	72″
Between Forks	96″
Fork Height	26″
Weight	1,350 lbs

Class 4

SKU #	QC600UPF9672
Rated Capacity	33,250 lbs
Carriage Width	96″
Tine Cross Section	3″ × 7″
Tine Length	72″
Between Forks	96″
Fork Height	34″
Weight	2,500 lbs
