TAG Main Pin Hydraulic Thumbs with Quick Link | QLHT Series | Payload Capacity 1,050 To 2,500 lbs | 165° To 205° Rotation | Machine Size 10-60 Tons | For Excavators
DESCRIPTION
The TAG QLHT Series Main Pin Hydraulic Thumbs with Quick Link provide enhanced rotation and flexibility for various excavation tasks, offering a rotation range of 165-205 degrees. Engineered with a self-contained design that integrates stops and lock-back functionality, these thumbs simplify installation and reduce setup time. Their robust construction, featuring replaceable hat bushings on pivot pins, ensures long-lasting performance, even in demanding environments.
Designed for excavators ranging from 20,000 to 120,000 lbs, the QLHT thumbs come with a narrow two-finger clamping mechanism for secure material handling. The Quick Link feature allows fast and accurate positioning, while extended length options are available for compatibility with quick-couplers. These thumbs deliver both durability and versatility, optimizing excavator functionality across a wide range of applications.
Key Features
- Quick Link Design: Allows fast positioning adjustments for efficient material handling.
- Two-Finger Clamping: Ensures a strong and secure grip on materials.
- Extended Length Options: Enhances reach and quick-coupler compatibility.
- Integrated Lock Back: Speeds up installation and improves control during operations.
- Replaceable Bushings: Facilitates maintenance and extends thumb lifespan.
- Durable Construction: Built to withstand demanding excavation tasks.
- Rotation Range: Provides 165-205 degrees of motion for greater flexibility.
- Self-Contained Design: Minimizes setup time with integrated stops and lock-back functionality.
- Wide Compatibility: Suited for excavators from 20,000 to 120,000 lbs.
- Quick-Coupler Ready: Ready for use with various quick-couplers for increased versatility.
Detailed Specifications
| Spec / Model | QLHT120 | QLHT150 |
|---|---|---|
| Weight Range (lbs) | 20,000 – 24,000 | 33,000 – 40,000 |
| Weight Range (tons) | 10 – 12 | 16.5 – 20 |
| Payload Capacity Weight (lbs) | 1050 | 1150 |
| Payload Capacity Weight (tons) | 0.525 | 0.575 |
| Spec / Model | QLHT200 | QLHT230 |
|---|---|---|
| Weight Range (lbs) | 40,000 – 45,000 | 45,000 – 60,000 |
| Weight Range (tons) | 20 – 22.5 | 22.5 – 30 |
| Payload Capacity Weight (lbs) | 1250 | 1550 |
| Payload Capacity Weight (tons) | 0.625 | 0.775 |
| Spec / Model | QLHT330 | QLHT450 |
|---|---|---|
| Weight Range (lbs) | 65,000 – 80,000 | 80,000 – 120,000 |
| Weight Range (tons) | 32.5 – 40 | 40 – 60 |
| Payload Capacity Weight (lbs) | 2100 | 2500 |
| Payload Capacity Weight (tons) | 1.05 | 1.25 |
Machine Fitting
24000 – 30000 LBS EXCAVATORS
| TAG MODEL | MFG | MODELS |
|---|---|---|
| QLHT120 | CASE | CX145,CX130,CX135 |
| QLHT120 | CAT | |
| QLHT120 | DEERE | 120,130,135 |
| QLHT120 | DOOSAN | 140 |
| QLHT120 | HITACHI | ZX120, ZX130,ZX135 |
| QLHT120 | HYUNDAI | 140 |
| QLHT120 | JCB | JS130,JS145 |
| QLHT120 | KOBELCO | 120,130,135 |
| QLHT120 | KOMATSU | PC120, PC128,PC138,PC158 |
| QLHT120 | LINK BELT | 130,135 |
| QLHT120 | NEW HOLLAND | E130 |
| QLHT120 | TAKEUCHI | TB1140 |
| QLHT120 | VOLVO | EC140 |
33000-40000 LBS EXCAVATOR
| TAG MODEL | MFG | MODELS |
|---|---|---|
| QLHT150 | CASE | CX160; 9020B |
| QLHT150 | CAT | 315C; M318 |
| QLHT150 | DEERE | 160G; 160D; 160CLC; 590D |
| QLHT150 | DAEWOO | S170-3; S175 |
| QLHT150 | HITACHI | Zx180; Z160LC EX150;EX160 |
| QLHT150 | HYUNDIA | R160-3 |
| QLHT150 | KOMATSU | PC150LC6; PC160LC7 |
| QLHT150 | KOBELCO | SK150-IV; SK160LC ED180; ED190 |
| QLHT150 | DOOSAN | Solar175-V |
| QLHT150 | NEW HOLLAND | E160; EH160; EW160 |
| QLHT150 | LINK BELT | 160LX; 2700Q JCB JS160 |
| QLHT150 | TEREX | TXC175; TXC180 |
| QLHT150 | VOLVO | EC160B |
40000-45000 LBS EXCAVATOR
| TAG MODEL | MFG | MODEL |
|---|---|---|
| QLHT200 | CASE | CX210; CX225; CX235; 9030B |
| QLHT200 | CAT | 318C; 320C; E200B |
| QLHT200 | DOOSAN | S225-V;S225N-V;S225S-V |
| QLHT200 | DAEWOO | 200-3; 220-3 S225; S255 |
| QLHT200 | DEERE | 180CW; 180G; 190GW; 200C; 200D, 225CRTS; 245G; 210G; 210CW; 690D/E |
| QLHT200 | HITACHI | Z200LC; Z210LC; Z225US |
| QLHT200 | LINK BELT | 210LX; LS2800Q |
| QLHT200 | NEW HOLLAND | EH215; EW200 |
| QLHT200 | HYUNDAI | R210LC7 |
| QLHT200 | SANY | SY215 |
| QLHT200 | JCB | JS220 |
| QLHT200 | TEREX | TXC225 |
| QLHT200 | KOBELCO | SK210; 200SR; 235SR |
| QLHT200 | KOMATSU | PC200LC-7; PC228 |
| QLHT200 | VOLVO | EC210B, EC220 |
45000-60000 LBS EXCAVATOR
| TAG MODEL | MFG | MODEL |
|---|---|---|
| QLHT230 | CASE | 9040; 9045; CX240; CX280 CX240D; CX290; CX270 |
| QLHT230 | HITACHI | Zx250; Zx290; Zx245 Zx240-3;Zx270-3; 270LCV |
| QLHT230 | LINK BELT | 225MSR; 240LX; 290LX; 340 |
| QLHT230 | NEW HOLLAND | EC215; EC240; E215 |
| QLHT230 | CAT | 322CL; 325C; 225B/D |
| QLHT230 | HYUNDIA | R250LC7 |
| QLHT230 | TEREX | TXC255 |
| QLHT230 | JOHN DEERE | 300G; 290G; 250G 230G; 270C; 230C; 790D/E |
| QLHT230 | JCB | JS220; JS260 |
| QLHT230 | SAMSUNG | 280 |
| QLHT230 | KOBELCO | SK250; SK220-IV; SK270-IV |
| QLHT230 | SANY | SY235 |
| QLHT230 | DOOSAN | Solar255-V |
| QLHT230 | KOMATSU | PC220; PC250; PC270-8; PC308 |
| QLHT230 | VOLVO | EC240B; 290B |
60000-80000 LBS EXCAVATOR
| TAG MODEL | MFG | MODEL |
|---|---|---|
| QLHT330 | CASE | CX330 |
| QLHT330 | DAEWOO | |
| QLHT330 | DEERE | 330,350,370,380 |
| QLHT330 | DOOSAN | DX300,DX340 |
| QLHT330 | HITACHI | ZX350,ZX380,ZX330,ZX370 |
| QLHT330 | HYUNDIA | |
| QLHT330 | LINK BELT | 225MSR; 240LX; 290LX; 340 |
| QLHT330 | NEW HOLLAND | EC215; EC240; E215 |
| QLHT330 | CAT | 322CL; 325C; 225B/D |
| QLHT330 | HYUNDIA | R250LC7 |
| QLHT330 | TEREX | TXC255 |
| QLHT330 | JOHN DEERE | 300G; 290G; 250G 230G; 270C; 230C; 790D/E |
| QLHT330 | JCB | JS220; JS260 |
| QLHT330 | SAMSUNG | 280 |
| QLHT330 | KOBELCO | SK250; SK220-IV; SK270-IV |
| QLHT330 | SANY | SY235 |
| QLHT330 | DOOSAN | DX |
| QLHT330 | KOMATSU | PC220; PC250; PC270-8; PC308 |
| QLHT330 | VOLVO | EC240B; 290B |
80000-120000 LBS EXCAVATOR
| TAG MODEL | MFG | MODEL |
|---|---|---|
| QLHT430 | CASE | CX450,CX460 |
| QLHT330 | DAEWOO | 450,470 |
| QLHT330 | DEERE | 450,470 |
| QLHT330 | DOOSAN | DX420,DX480 |
| QLHT330 | HITACHI | EX450,ZX450,ZX470 |
| QLHT330 | HYUNDIA | R450,R500 |
| QLHT450 | JCB | JS450,JS460 |
| QLHT330 | LINK BELT | 460 |
| QLHT330 | JCB | JS220; JS260 |
| QLHT330 | SAMSUNG | |
| QLHT330 | KOBELCO | SK480,SK400 |
| QLHT330 | NEW HOLLAND | EX450 |
| QLHT330 | KOMATSU | PC400,PC450 |
| QLHT330 | VOLVO | EC460 |
