Product Description
TAG SDR Ripping Buckets | Width 12″–36″ | Capacity 3.95–12.00 Cubic ft | Machine Size 7-20 Tons | For Backhoes
DESCRIPTION
The TAG SDR Ripping Buckets are engineered to break through tough ground conditions including fractured rock, frost, shale, and compacted subgrades. Each bucket features five (5) rear-mounted ripper shanks that penetrate and loosen material before the primary edge engages, dramatically improving digging efficiency and tool longevity.
Tailored for backhoes in the 14,000–20,000 lb operating range, these buckets come in widths from 12″ to 36″, giving operators options for tight trenching or broader cuts. Ideal for utility contractors, demolition crews, and excavators working in unforgiving soil profiles, these buckets deliver unmatched breakout force and high resistance to wear.
Key Feature
- 5 Rear-Mounted Ripper Shanks Pre-fracture hard soils for easier excavation and reduced bucket stress.
- Severe Duty Build Reinforced shell, edges, and gussets provide durability in rock-heavy conditions.
- Optimized Widths from 12″–36″ Narrow trenching to wide-area excavation for flexibility on-site.
- Replaceable Digging Teeth Sharp, hard-faced tips improve cutting and can be serviced in the field.
- Designed for 14–16 ft Boom Backhoes Matches common rubber-tire machines in the 14K–20K lb class.
- Inventory Availability Common models may be stocked by LEC or TAG MFG—call to confirm lead times.
Detailed Specifications
Part # |
Width (in) |
Capacity (ft³) |
Teeth Qty |
Weight (lbs) |
|---|---|---|---|---|
| 1249R5 | 12″ | 3.950 | 3 | 500 |
| 1649R5 | 16″ | 4.900 | 4 | 550 |
| 1849R5 | 18″ | 5.650 | 4 | 575 |
| 2449R5 | 24″ | 7.785 | 5 | 630 |
| 3049R5 | 30″ | 10.000 | 5 | 680 |
| 3649R5 | 36″ | 12.000 | 6 | 735 |
Host Machine Compatibility
| BRAND | MODELS |
| Case | 580, 580M, 580N, 590, 590M, 590N |
| Cat | 416C, 416E, 420D, 420E, 428F, 432F, 434F |
| John Deere | 310C, 310D, 310E, 310G, 310J, 310K, 310SE, 310SG, 310SJ, 310SK, 410E, 410G, 410J, 410K, 510 |
| Ford | 455, 555, 555E, 655, 665E, 675E |
| Komatsu | WB140, WB146-5, WB150, WB156-5 |
| New Holland | LB75, LB90, LB95, LB110, LB115, B95C, B110C |
| Volvo | BL60, BL70 |
Manuals & Documents
General Warranty Info:
- Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
- The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
- Expendable components and “wear parts” including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
- Please reach out to us for any specific warranty information needed about products and parts you can’t find!
