TAG Top-Mount Quick Coupler for Excavators – Adjustable 1.25″–3.00″ Pin, Universal Fit for 1–22 Ton Machines

Description

Product Description

TAG Top Mount Or Top Cap | Quick Coupler | 1.25″–3.00″ Pin | Machine Size 1–22 Ton |  For Excavators

DESCRIPTION

The TAG Quick Coupler Top Mount Series provides a rugged and adaptable solution for mounting hydraulic attachments such as augers, hammers, and breakers. Designed for excavators ranging from 1 to 22 tons (2,500–45,000 lbs), these universal top mounting brackets are available in Pin-On, Wain-Roy style hook, and Wedge Lock configurations to suit a wide range of coupler systems.

Each bracket is built for strength and compatibility, with customizable options to fit specific attachment requirements. Whether you’re outfitting a compact utility machine or a mid-size excavator, TAG top mounts ensure secure, efficient tool integration for demanding jobsite conditions.

Key Features

• Excavator Compatibility: Fits 1–22 ton machines (2,500–45,000 lbs)
• Mounting Styles: Available in Quick Coupler (Wain-Roy hook or Wedge Lock) and Pin-On configurations
• Universal Fit: Designed to mount augers, hammers, breakers, and other hydraulic tools
• Customizable Options: Brackets can be tailored to specific attachment dimensions
• Heavy-Duty Construction: Engineered for durability and long-term use
• Compact & Mid-Size Coverage: Supports a wide range of excavator classes and coupler systems

Detailed Specifications

Quick Coupler – Wain-Roy Style Hook
Pin Size	Part #	Weight (lbs)	Excavator Class (Tons)
1.25″	UTM27	110	1.25 – 7 Ton
1.75″	UTM30	150	6 – 8 Ton
2.50″	UTM33	250	10 – 16.5 Ton
3.00″	UTM38	430	16.5 – 22.5 Ton

Quick Coupler – Wedge Lock (Deere / Hitachi)
Model	Part #	Weight (lbs)	Excavator Class (Tons)
Deere 17	UTM04	85	1.25 – 2 Ton
Deere 26/30/27/35	UTM05	85	2 – 3 Ton

Host Machine Compatibility

UTM27
2500-6000 LBS	EXCAVATORS
BRAND	MODELS
BOBCAT	E14,E16,E20,323,324,325,328
CASE	CX25,CX27,CX27B,CX31, CX14,CX17,CX17B
CAT	301.5,301.6,301.8,301.6C,301.8C
DOOSAN	015
GEHL	143,153,193,223,253,EC17,192,222
HITACHI	EX17,ZX17
HYUNDIA	R15-7,R16-7,R22-7
IHI	17VXE,15VX,15NX,10G,12G,14G,15J,18J
JCB
JOHN DEERE	15,17 ZTS,17C,17D, 17G
KOBELCO	13SR,SK13SR,SK15SR
KOMATSU	PC18MR-2,PC20MR-2,PC15R-8,PC15MRX
KUBOTA	B20,B21,U15,KX41-3
MUSTANG	1403,1503,1903,2203,2503,1902,2202
NEW HOLLAND	EC15,E15
TAKEUCHI	TB216,TB016,TB014
TEREX	HR1.5,TC15,HR1.6,TC16
VOLVO	EC15B,EC20B
WACKER	1404,2503
YANMAR	VIO15-2,VIO17,VIO20-2,VIO15-3,VIO20-3,B15

UTM27
6000-10000 LBS	EXCAVATORS
BRAND	MODELS
BOBCAT	331, 334, 430ZHS, E26, E32, E35
CASE	CX27B, CX31B, CX36B, CX25, CX27, CX31, CX36, D100, D125
CAT	302.5C, 303.5CCR, 303CCR, 302.5, 303.5, 303CR
DEERE	27C, 27D, 27ZTS, 110, 35ZTS, 35C, 35D
DOOSAN	SOLAR 030, SOLAR 035
HITACHI	EX27, EX30, EX35, ZX27, ZX35
HYUNDAI	R28-7, R35-7, R36N-7
IHI	25NX-2, 28N-2, 30NX-2, 35N-2, 35NX
JCB	803, 8040, 8045
KOBELCO	27SR-3, 30SR-3, 35SR-3, SK25, SK27, SK30, SK35
KOMATSU	PC30MR-2, PC27MR-2, PC30MR, PC35MR
KUBOTA	U25, U35, L39
NEW HOLLAND	E27, EC30, E35, EC25, EH35
TAKEUCHI	TB035, TB0125, TB135, TB138FR, TB228, TB235, TB240, TB228, TB230, TB235
TEREX	HR14/TC29, TC15, HR1.6, TC16, HR2.0, TC20
VOLVO	EC25, EC30, EC35, ECR28, ECR38
YANMAR	VIO25, VIO35

UTM27
10000-12000 LBS	EXCAVATORS
BRAND	MODELS
BOBCAT	337, 341, 435ZHS, E42,E45,E50,E55
CASE	CX50B, CX50, CX47
CAT	304CCR, 305CCR, 304.5, 304CR, 305CR
DAEWOO	50,55
DEERE	50ZTS, 50C, 50D, 50G
DOOSAN	55V, 55W
GEHL	503Z,603,502,602,652
HYUNDAI	R55-7,R55W-7
IHI / KATO	45V4,55V4,60V4,45NX,55NX
JCB	8040,8045,8050,8052,48Z,51R,55Z
HITACHI	EX50, ZX50
HYUNDAI	R55-7, R55W-7
KOBELCO	50SR-3, SK045, SK050
KOMATSU	PC40MR-2, PC50MR-2, PC58UU-3, PC45
KUBOTA	KX151-3, KX61, KX161-3, U45
NAGANO	NS-45
NEW HOLLAND	E50, EC45, EH45
TAKEUCHI
TEREX	HR16/TC35, HR3.7/TC37, TC48, TC50, TC60
THOMAS	T45
VOLVO	EC45PRO, EC50BPRO, ECR58, EW55B, EC55B
WACKER	50Z3,6003,6503
YANMAR	VIO40-3, VIO50-3

UTM27
12000-14000 LBS	EXCAVATOR
BRANDS	MODELS
DEERE	60D,60G
JCB	8055,8065,57C
KUBOTA	U55
TAKEUCHI	TB145,TB153,TB250,TB260
VOLVO	ECR58

UTM30
12000-16000 LBS	BACKHOE
BRANDS	MODELS
BOBCAT	E63,E80,E85,442,
CASE	580, 590
CAT	416C, 420D, 428F, 432F, 434F
DAEWOO
DEERE	310K, 310SK, 410K 310J, 310SJ, 410J 310G, 310SG, 410G, 510
DOOSAN
FORD	455, 555, 655 555E, 655E, 675E
JCB	214, 3CX, 4CX
KOMATSU	WB146-5/156-5, WB140/150
NEW HOLLAND	LB75, LB115, LB90, LB110
VOLVO	BL60, BL70

UTM30
12000-16000 LBS	EXCAVATOR
BRANDS	MODELS
BOBCAT	E63,E80,E85,442,
CASE	580, 590 9007,CX75,CX80
CAT	307C,308C CR,E70B 416C, 420D, 428F, 432F, 434F
DAEWOO
DEERE	310K, 310SK, 410K 310J, 310SJ, 410J 310G, 310SG, 410G, 510
DOOSAN	S75-V, S70-III, SOLAR75-V
FORD	455, 555, 655 555E, 655E, 675E
GEHL
HYUNDAI	R75-7, R80-7
IHI / KATO	65VX, 80VX, 55N, 65NX, 80NX
JCB	214, 3CX, 4CX, 8085, JS70
HITACHI	Z80L, Z75US
KOBELCO	SK70SR, 80CS
KOMATSU	WB146-5/156-5, WB140/150 PC60 ,PC75R-2, PC78
KUBOTA
LINK BELT	75, 80, 1600Q
NAGANO
NEW HOLLAND	LB75, LB115 LB90, LB110
TAKEUCHI	TB290, TB285, TB180FR, TB175
TEREX	HR32, TC75
THOMAS
VOLVO	ECR88, BL60, BL70
WACKER
YANMAR	VIO75,VIO70, B7, B7-5A

UTM33
20000-24000 LBS	BACKHOE
BRAND	MODELS
CAT	446
DEERE	710L, 710K, 710J, 710G, 710D, 710C, 710B, 710A

UTM33
24000-33000 LBS
BRANDS	MODELS
CASE	CX145, CX130, CX135SR, 9010
CAT	311C, 312C, 314C, E120B
DAEWOO	S130, S140
DEERE	130G, 120C, 135CRTS, 490D/E
DOOSAN	SOLAR140-V
GEHL
HITACHI	Z110, Z120, Z130, Z135US
HYUNDAI	R140LC-7
IHI / KATO
JCB	JS130, JS145
KOBELCO	SK135SR, SK115SRDZ, SK120-IV, SK130-IV, ED150
KOMATSU	PC120-6, PC128, PC138, PC158
KUBOTA
LINK BELT	LS2650Q, 130LX, 135
NAGANO
NEW HOLLAND	E130, EH130-LC
SANNY	SY135
TAKEUCHI	TB1140
TEREX	TXC140
THOMAS
VOLVO	EC140B
WACKER
YANMAR

UTM38
33000-40000 LBS	EXCAVATOR
BRANDS	MODELS
CASE	CX160, 9020B
CAT	315C, M318
DAEWOO	S170-3, S175
DEERE	160G, 160D, 160CLC, 590D
DOOSAN	SOLAR175-V
GEHL
HITACHI	ZX180, Z160LC, EX150, EX160
HYUNDAI	R160-3
IHI / KATO
JCB	JS160
KOBELCO	SK150-IV, SK160LC, ED180, ED190
KOMATSU	PC150LC6, PC160LC7
KUBOTA
LINK BELT	160LX, 2700Q
NAGANO
NEW HOLLAND	E160, EH160, EW160
SANNY
TAKEUCHI
TEREX	TXC175, TXC180
THOMAS
VOLVO	EC160B
WACKER
YANMAR

UTM38
40000-45000 LBS	EXCAVATOR
BRANDS	MODELS
CASE	CX210, CX225SR, 9030B
CAT	318C, 320C, E200B
DAEWOO	200-3, 220-3, S225, S255
DEERE	200CLC, 225CRTS, 210CW, 690D/E
DOOSAN	S225-V, S225M-V, S225S-V
GEHL
HITACHI	Z200LC, Z210LC, Z225US
HYUNDAI	R210LC7
IHI / KATO
JCB	JS220
KOBELCO	SK210, 200SR, 235SR,
KOMATSU	PC200LC-7
KUBOTA
LINK BELT	210LX, LS2800Q
NAGANO
NEW HOLLAND	EH215, EW200
SANNY
TAKEUCHI
TEREX	TXC225
THOMAS
VOLVO	EC210B
WACKER
YANMAR
