Tag Universal Spring-Loaded Manual Quick Coupler for 2–4 Ton Excavators | Reliable One-Hand Release Mechanism

Description

Product Description

TAG Universal Spring-Loaded Manual Release Quick Coupler | Machine Size 2–4 Ton | For Excavators

DESCRIPTION

The TAG Universal Spring-Loaded Manual Release Quick Coupler is an economical and efficient solution designed to streamline attachment changes on compact excavators in the 4,000–8,000 lb (2–4 ton) class. This coupler is ideal for operators seeking a mechanical, non-hydraulic system that ensures safe locking and fast release when picking up OEM pin-on style buckets.

Featuring a spring-loaded lever mechanism and manual lock system, this coupler requires no special tools, wiring, or hydraulics. The top half of the coupler is customized to match machine-specific geometry, ensuring proper fit, alignment, and reliability. Each unit includes a complete set of dead pins for installation.

Key Features

• Excavator Compatibility: Designed for machines in the 4,000–8,000 lb range.
• Coupler Type: Universal spring-loaded lever release with manual locking mechanism.
• Bucket Fitment: Picks up OEM pin-on style buckets (horizontal pin geometry).
• Top Half Configuration: Machine-specific geometry ensures precise fit.
• Dead Pins Included: Each coupler ships with one full set of dead pins.
• Operation Style: Mechanical quick release; no hydraulics required.
• Ideal Use Cases: Grading, trenching, landscaping, and general excavation.
• Installation Simplicity: No wiring or plumbing required; straightforward mounting.

Detailed Specifications

Model: MC05-1

Attribute	Specification
Machine Weight Class	4,000–6,000 lbs
Excavator Size	2–3 Ton
Estimated Coupler Weight	~120 lbs
Compatible Machines	Takeuchi TB125 / TB228 / TB230

Model: MC05-2

Attribute	Specification
Machine Weight Class	5,000–8,000 lbs
Excavator Size	2.5–4 Ton
Estimated Coupler Weight	~130 lbs
Compatible Machines	Takeuchi TB135 / TB138FR / TB235 / TB240

Model: MC05-3

Attribute	Specification
Machine Weight Class	4,000–8,000 lbs
Excavator Size	2–4 Ton
Estimated Coupler Weight	~135 lbs
Compatible Machines	Case CX31B / CX36B, Kobelco SK30SR-3 / SK35SR-3, New Holland EH30B / EH35B

Model: MC05-4

Attribute	Specification
Machine Weight Class	4,000–6,000 lbs
Excavator Size	2–3 Ton
Estimated Coupler Weight	~125 lbs
Compatible Machines	Ditch Witch MX35, Komatsu PC27MRX-1 / PC28UU / PC27MR-2

Model: MC05-5

Attribute	Specification
Machine Weight Class	4,000–8,000 lbs
Excavator Size	2–4 Ton
Estimated Coupler Weight	~140 lbs
Compatible Machines	Komatsu PC27R-8E / PCB4U-2 / PC35 / PC35MR-1 / PC35MR-2 / PC38UU-3

Model: MC05-7

Attribute	Specification
Machine Weight Class	4,000–6,000 lbs
Excavator Size	2–3 Ton
Estimated Coupler Weight	~115 lbs
Compatible Machines	Yanmar CLB40

Model: MC05-8

Attribute	Specification
Machine Weight Class	4,000–8,000 lbs
Excavator Size	2–4 Ton
Estimated Coupler Weight	~135 lbs
Compatible Machines	John Deere 35D

Model: MC05-9

Attribute	Specification
Machine Weight Class	4,000–8,000 lbs
Excavator Size	2–4 Ton
Estimated Coupler Weight	~145 lbs
Compatible Machines	Gehl Z25 / Z27 / Z35 / 270Z; Deere 25 / 30; Kobelco SK25SR-6E; Mustang 250Z / 350Z; Yanmar B27-2B / B3 / B37-2B / SV40 / VIO25 / VIO27 / VIO35

Model: MC05-10

Attribute	Specification
Machine Weight Class	5,000–8,000 lbs
Excavator Size	2.5–4 Ton
Estimated Coupler Weight	~130 lbs
Compatible Machines	Case CX33C / CX37C

Host Machines Compatibility

Part #	Compatible Models
MC05-1	Takeuchi TB125, TB228, TB230
MC05-2	Takeuchi TB135, TB138FR, TB235, TB240
MC05-3	Case CX31B, CX36B; Kobelco SK30SR-3, SK35SR-3; New Holland EH30B, EH35B
MC05-4	Ditch Witch MX35; Komatsu PC27MRX-1, PC28UU, PC27MR-2
MC05-5	Ditch Witch MX35; Komatsu PCB4U-2, PC27R-8E, PC30MRX, PC35, PC35MR-1, PC35MR-2, PC35R-8E, PC38UU-3
MC05-7	Yanmar CLB40
MC05-8	John Deere 35D
MC05-9	Gehl 270Z, Z25, Z27, Z35; Deere 25, 30; Kobelco SK25SR-6E; Mustang 250Z, 350Z; Yanmar B27-2B, B3, B37-2B, SV40, VIO25, VIO27, VIO35
MC05-10	Case CX33C, CX37C
