TecnoGen Mega Silent Series 58kW 70kVA FP70FQ Generator
DESCRIPTION
TecnoGen’s 70kVA generator uses the FPT engine coupled to an industry standard Leroy Somer alternator producing 58kW of prime power. Standard features include camlocks, block heater and battery charger. The Deep Sea controller makes retrieving vital stats like fuel levels and start logs easy. The tripled sealed doors and 2″ thick insulation throughout gives this gen a 55dBA rating.
The internal fuel capacity is 79 gallons allowing for a run time of up to 26,3 hours @ 75% load. The convenient external fuel hook-up allows for quick connect to an additional fuel cell if needed. The TecnoGen Mega Silent series is built for the entertainment world. Available on trailer or skid mounted.
Key Features
- 58kW Prime Power Output: Efficient power generation for demanding applications.
- Low Noise Operation: Rated at 55 dBA @ 23 feet, minimizing disruption.
- Extended Runtime: 79-gallon fuel tank offers up to 26.3 hours of use at 75% load.
- FPT F34 Engine: EPA Tier 4F compliant for clean, efficient operation.
- Durability: Triple-sealed doors and 2″ insulation for quiet, long-lasting performance.
- Deep Sea Controller: Provides easy access to operational stats, including fuel levels and logs.
Detailed Specifications
| Specification |
Details |
| Prime Power |
58 kW |
| Sound Level @ 23′ |
55 dBA |
| Controller |
Deep Sea |
| Alternator |
Leroy Somer |
| Engine Model |
FPT F34 |
| EPA Level |
Tier 4F |
| Horsepower |
98 |
| Fuel Capacity |
79 Gallons |
| Run Time @ 75% |
26.3 Hours |
| Length |
102″ |
| Width |
44″ |
| Height |
72″ |
| Weight |
6,750 lbs |
Generator Specs
| Specification |
Details |
| Prime Power (PRP) kW |
58.0 |
| Prime Power (PRP) kVA |
72.5 |
| Standby Power (LTP) kW |
64.0 |
| Standby Power (LTP) kVA |
80.0 |
| Rated Power Factor (cos φ) |
0.8 |
| RPM |
1800 |
| Voltage (1PH) |
240/120V |
| Voltage (3PH) |
480/277V, 208/120V |
| Rated Frequency |
60 Hz |
| Controller Brand |
Deep Sea |
| Controller Model |
DSE7310 |
| Sound Level @ 23′ (no load) |
55 dB |
Amps
| Configuration |
Amps |
| Single Phase 120V |
193 × 2 |
| Single Phase 240V |
193 |
| Three Phase 208V |
201 |
| Three Phase 480V |
87 |
Engine Specs
| Specification |
Details |
| Make |
FPT |
| Model |
F34 |
| EPA Level |
Tier 4F |
| No. Cylinders |
4 |
| Gross HP |
98 |
| External Fuel Valve |
Yes |
| Fuel Containment |
110% |
Fuel Consumption
| Specification |
Details |
| Fuel Type |
Diesel |
| Fuel Capacity (gal.) |
79 |
| Fuel Consumption @ 75% (PRP) |
3.0 gal/h |
| Run Time @ 75% |
26.3 hrs |
DEF
| Specification |
Details |
| DEF Tank Capacity (gal.) |
5 |
Alternator Data
| Specification |
Details |
| Alternator Brand |
Leroy Somer |
| Alternator Model |
LSA 44.3S2 |
| PRP Power (kVA) |
76 |
| LTP Power (kVA) |
84 |
| IP Protection |
23 |
| Voltage Regulator |
±0.25% AREP |
| Short-Circuit Current |
300% : 10s |
Weights & Dimensions (Skid w/ Trailer)
| Specification |
Details |
| Dry Weight (lbs.) |
8,450 |
| Wet Weight (lbs.) |
7,829 |
| Length (in.) |
173 |
| Width (in.) |
74 |
| Height (in.) |
78 |
Weights & Dimensions (Skid w/o Trailer)
| Specification |
Details |
| Dry Weight (lbs.) |
6,129 |
| Wet Weight (lbs.) |
6,750 |
| Length (in.) |
102 |
| Width (in.) |
44 |
| Height (in.) |
72 |
MEGA SILENT SERIES
By using patented VSi technology to adjust the fans to cool only as necessary to maintain proper temperature, TecnoGen creates one of the most fuel efficient generators on the market, not to mention the quietest!
CUSTOMER FOCUSEDWith TecnoGen, you’ll always get a commitment to superior service, fast turnaround times and real 24/7 support.
FOR THE ENTERTAINMENT WORLDPerfect for the entertainment, events and movie sectors, TecnoGen designed the Mega Silent Series paying specific attention to low noise level, operating temperature and low fuel consumption.
