Trilo S3 Vacuum Trailer for Tractors – 74.8″ Working Width, 3.9-Yard Capacity, 35–80 HP Pull-Type

Description

Product Description

TRILO Vacuum Trailer | Model S3 | Working Width 74.8″ | Length 159″ | Loading Capacity 3.9 Cubic Yard | Horsepower 35-80 HP | Pull Type | For Tractors

DESCRIPTION

The TRILO S3 Vacuum Trailer is a compact, high-efficiency debris collection system designed for sweeping and vacuuming in a single pass. With a 3 m³ high-tipping bin and powerful PTO-driven fan, it’s ideal for maintaining turf quality in parks, campgrounds, sports fields, and public spaces. The S3 features large low-pressure tires, adjustable airflow, and EU road transport approval—making it both field-ready and road-legal. Optional accessories like a 6-meter wander hose extend its reach to hard-to-access areas, while its one-person operation and high working speed ensure maximum productivity.

Key Features

• 74.8-Inch Working Width Perfect for sweeping and collecting leaves, grass clippings, and debris across parks, campuses, and sports fields
• 3.9 Cubic Yard Loading Capacity Handles high-volume material collection with fewer unload cycles for increased productivity
• Powerful 700 mm Fan with 4 Blades Generates 280 m³/min airflow for strong suction and efficient debris transfer
• PTO-Driven for 35–80 HP Tractors Compatible with standard 540 RPM PTO systems for sweep, verticut, and suction hose operations
• Optional 6-Meter Wander Hose (Ø 200 mm) Enables vacuuming in hard-to-reach areas like fence lines, tree bases, and building edges
• Manual Tipping Bin with 1.6 m Height Allows easy unloading into trailers or compost piles without additional equipment
• Softtrac 26.5 x 14.00-12 Tires Provide low ground pressure for turf-safe operation on sensitive surfaces
• Compact Dimensions (159″ L × 74.8″ W × 72.8″ H) Maneuverable in tight areas while offering full coverage and capacity
• Hydraulic System: 180 Bar, 20 l/min Flow Operates tipping and optional accessories with a single double-acting connection
• Noise Level: 90 dB(A) Balanced for powerful operation while remaining within acceptable sound thresholds
• Durable Build (2734 lbs) Ensures stable towing and long-term reliability in demanding field conditions

Detailed Specifications

Attribute	Specification
Model	S3
Fan Diameter	Ø 700 mm (27.5″)
Fan Blades	4
Air Capacity	280 m³/min
Noise Level	90 dB(A)
Loading Capacity	3 m³ (3.9 yd³)
Working Width	1.50 m (4.9 ft)
Dimensions (L×W×H)	4.05 × 1.90 × 1.85 m (13 × 6.2 × 6 ft)
Weight	1240 kg (2734 lbs)
Tyres	Softtrac 26.5 x 14.00-12
PTO Requirements	540 RPM
Sweep & Collect PTO Power	35–70 HP (26–52 kW)
Verticut PTO Power	60–80 HP (45–60 kW)
Suction Hose PTO Power	35–50 HP (26–37 kW)
Hydraulic Pressure	180 bar
Hydraulic Flow Rate	20 l/min
Hydraulic Connections	1 × double acting
Wander Hose (Optional)	Ø 200 mm × 6 m (5 + 1 m)
Tipping Height	1.6 m
