Product Description
Rankin 3-Point Tractor Tandem Disc Harrow Model DH30-96 | 96″ Working Width | 45 HP For Tractor
Included Options:
- Heavy-Duty 1-1/8″ Square High Carbon Gang Bolts: For demanding tasks in tougher soil conditions.
- Additional Blade Configurations: Custom blade configurations are available upon request.
DESCRIPTION
The Rankin TANDEM DISC HARROWS DH Series Model DH30-96 is designed to provide reliable performance for various soil preparation tasks. This durable and efficient disc harrow is ideal for medium to heavy-duty applications such as breaking up soil clods, incorporating crop residue, and preparing seedbeds. With robust construction and customizable settings, the DH30-96 ensures long-lasting performance across different field conditions.
Key Features
- 7-1/2″ Blade Spacing: Ensures effective soil penetration and thorough mixing.
- Triple Sealed Ball Bearings: Provides smooth operation and extends the equipment’s durability.
- Adjustable Gang Angles: Customize angles for optimal performance in various soil conditions.
- 1″ Square High Carbon Gang Bolts: Offers strength and reliability for standard soil preparation tasks.
- 1-1/8″ Square High Carbon Gang Bolts (Heavy-duty Series): Available for more demanding applications.
- Notched Front, Plain Rear Blades: Enhances soil cutting and residue mixing capabilities for thorough preparation.
Detailed Specifications
| Specification | Details |
|---|---|
| SKU | RAN-DH30-96 |
| Weight | 985 lbs |
| Model | DH30-96 |
| Horsepower Required | 45 HP |
| Overall Width | 96″ (8 Feet; 244 cm) |
| Working Width | 96″ (8 Feet; 244 cm) |
| Blade Configuration | 28 Notched Blades, 18″ Diameter |
| Blade Spacing | 7-1/2″ |
| Hitch Connection Type | Category 1, 3-Point Hitch, Quick-Hitch Compatible |
| Color | Yellow & Black |
| Manufacturer | Rankin Equipment |
In Package
- Rankin 96″ Tandem Disc Harrow (DH30-96)
- 28 Notched Blades (18″ Diameter)
- Triple Sealed Ball Bearings
- Category 1, 3-Point Hitch (Quick-Hitch Compatible)
- User Manual & Assembly Instructions
Manuals & Description
General Warranty Info:
- Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
- The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
- Expendable components and “wear parts” including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
- Please reach out to us for any specific warranty information needed about products and parts you can’t find!
