Product Description
RockZone Soil & Dirt Mixer | Model MXR-D20 LH | Mixing Width 45″ | 17 To 28 Tons | For Excavator
DESCRIPTION
The RockZone MXR-D20 LH is a cutting-edge soil mixing attachment designed for heavy-duty applications, perfect for large-scale excavation projects. Engineered to fit 17-28 ton excavators, this high-performance attachment features a longer housing design, allowing for deeper material penetration and complete material reduction, making it ideal for tackling challenging mixing jobs. With its customizable paddle layouts, adjustable drum width (up to 45 inches), and an efficient hydraulic system, the MXR-D20 LH offers versatility and unmatched performance. Whether you’re working with soil, dirt, or other dense materials, this attachment maximizes productivity and ensures smooth operation.
Equipped with a 95 HP motor and a flow rate of 40-55 GPM, the MXR-D20 LH excels in both power and efficiency. Its rugged construction and superior torque (13,206 ft-lbs) ensure reliable performance even in the toughest conditions. If you’re looking to take your excavation projects to the next level, the MXR-D20 LH is a must-have addition to your equipment lineup.
Key Features
- Longer Housing for Deeper Penetration: The MXR-D20 LH features a longer housing body, offering deeper penetration for complete reduction of material obstructions between the drums and housing.
- Customization Options for Versatile Applications: Tailor the paddle layout, drum width, and amendment feeder system piping to suit your specific project needs. Ideal for medium to large-scale soil mixing tasks.
- Powerful Hydraulic System: With a 95 HP motor and a flow rate of 40-55 GPM, the MXR-D20 LH provides high performance, ensuring smooth and efficient operation in any mixing environment.
- Heavy-Duty Torque Performance: Delivers maximum torque of 13,206 ft-lbs (17.9 kNm), making it suitable for handling tough soil and other dense materials.
- Durable and Reliable Construction: Built to withstand the rigors of industrial use, the MXR-D20 LH guarantees long-lasting durability and consistent performance.
- Adjustable Drum Width for Flexibility: The 45-inch drum width (1150 mm) provides flexibility to handle various soil types and mixing requirements, improving efficiency on-site.
- Max Operating Pressure of 5800 psi: High operating pressure capability ensures that the attachment works optimally under demanding conditions.
- Designed for 17-28T Excavators: Compatible with excavators in the 17-28 ton range, allowing for seamless integration with your existing heavy equipment.
- Enhanced Mixing Efficiency: Drum speed ranging from 50-75 RPM optimizes mixing efficiency and ensures a consistent output.
- Reduced Downtime: With its robust design, the MXR-D20 LH minimizes maintenance needs, reducing downtime on the job site.
- Improved Soil Consistency: Achieve better soil consistency with advanced mixing capabilities, making it perfect for construction, landscaping, and agricultural applications.
- Ideal for Large-Scale Projects: The powerful mix of customizability, torque, and power makes the MXR-D20 LH the perfect choice for large, demanding projects.
- Simple Installation: Easy to install on your 17-28 ton excavator, ensuring that you’re up and running quickly with minimal setup time.
- High-Torque Direct Drive System: The Rockwheel Direct Drive ensures that every turn of the drum delivers maximum torque for optimal mixing.
Detailed Specifications
| Specification | Detail |
|---|---|
| Model | MXR-D20 LH |
| Excavator Compatibility | 17-28 Tons Excavator |
| Hydraulic Input Power | 95 HP (70 kW) |
| Required Flow Rate | 40-55 GPM (150-208 l/min) |
| Operating Pressure (Max) | 5800 psi (400 bar) |
| Drum Speed | 50 – 75 RPM |
| Max Torque | 13,206 ft-lbs (17.9 kNm) |
| Drum Width | 45 inches (1150 mm) |
| Weight (Without Bracket) | 3000 lbs (1365 kg) |
| Max Operating Pressure | 5800 psi (400 bar) |
| Drum Length | 45 inches (1150 mm) |
| Hydraulic Flow Rate | 40-55 GPM (150-208 l/min) |
| Compatibility | Compatible with 17-28T Excavators |
| Power Source | Hydraulic Motor (95 HP / 70 kW) |
Manuals & Documents
- Product Brochure
- Product Specification
General Warranty Info:
- Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
- The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
- Expendable components and “wear parts” including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
- Please reach out to us for any specific warranty information needed about products and parts you can’t find!
