Product Description
RockZone Soil & Dirt Mixer | Model MXR-D20 | Width 45 Inches | 17 To 28 Tons | For Excavators
DESCRIPTION
The RockZone MXR-D20 Soil Mixer Attachment is engineered to handle the toughest soil mixing challenges with unmatched efficiency and precision. Designed for 17 to 28-ton excavators, this attachment ensures superior performance, whether you’re tackling large-scale soil amendment projects, blending soil, or preparing substrates for construction.
With a mixing width of 45 inches, the MXR-D20 can process large volumes of material quickly, while its robust 95 horsepower hydraulic input guarantees maximum power output for even the most demanding applications. Featuring customizable paddle layouts and feeder system piping, it offers the flexibility to tailor the mixer’s performance to your exact needs.
Its heavy-duty construction, including a max torque of 13,206 ft-lbs, ensures durability in the most challenging conditions, while the adjustable drum speed (50-75 RPM) provides the ability to fine-tune the mixing process. The MXR-D20 is the ideal solution for medium-to-large-scale soil mixing, blending, and compaction operations. Maximize your operational efficiency and take your projects to the next level with RockZone’s top-tier engineering and design.
Key Features
- Efficient Soil Mixing: The MXR-D20 delivers exceptional soil mixing, making it perfect for large-scale soil preparation on construction sites.
- Versatile Compatibility: Designed for 17 to 28-ton excavators, the attachment works seamlessly with a wide range of machinery, enhancing your fleet’s flexibility.
- Customizable Design: Tailor the paddle layout and amendment feeder system piping to suit your unique project needs and maximize operational efficiency.
- High Hydraulic Power: Equipped with a 95-hp hydraulic input, this mixer provides plenty of power to ensure smooth, uninterrupted mixing.
- Durable Construction: With heavy-duty materials, the MXR-D20 is built to withstand harsh job site conditions and extend the life of the attachment.
- Adjustable Drum Speed: The 50-75 RPM drum speed allows you to control the mixing speed for different material types and project requirements.
- Increased Torque: Offering 13,206 ft-lbs of torque, the MXR-D20 can handle dense and challenging soil mixtures with ease.
- Wide Mixing Width: With a 45-inch mixing width, this attachment is perfect for large-area projects, saving you time and reducing labor costs.
- Optimal Hydraulic Flow: Requires 40-55 GPM hydraulic flow, ensuring consistent and high-performance mixing without overloading your excavator.
- Max Operating Pressure: The MXR-D20 is designed to operate at a maximum pressure of 5800 psi, ensuring superior efficiency under tough conditions.
- High-Quality Drum Construction: The drum is built to last, providing reliable, consistent performance over extended periods of use.
- Efficient Material Handling: Designed for optimal material handling, it mixes a variety of materials from soils to aggregates, with ease.
- Easy to Maintain: The MXR-D20’s design includes low-maintenance features, making it easier to keep your equipment in top shape and reducing downtime.
- Safe and Secure Operation: With enhanced safety features, the attachment provides a secure solution for contractors looking for dependable performance.
- Heavy-Duty Performance: Perfect for handling large-scale projects, the MXR-D20 offers the heavy-duty performance your work site demands.
Detailed Specifications
| Specification | Details |
|---|---|
| Model | MXR-D20 |
| Excavator Compatibility | 17-28 Tons |
| Hydraulic Input Power | 95 HP (70 kW) |
| Required Flow Rate | 40-55 GPM (150-208 l/min) |
| Max Operating Pressure | 5800 psi (400 bar) |
| Drum Speed | 50-75 RPM |
| Max Torque | 13,206 ft-lbs (17.9 kNm) |
| Mixing Width | 45 Inches (1150 mm) |
| Weight (w/o Bracket) | 3000 lbs (1365 kg) |
| Drum Width | 45 Inches (1150 mm) |
| Mixing Capacity | High Volume |
| Feeder System | Customizable Options |
| Hydraulic Flow Range | 40-55 GPM (150-208 l/min) |
| Attachment Type | Soil Mixer |
| Operating Pressure | 5800 psi (400 bar) |
