TAG High Tip Roll Out Bucket | Width 92″-144″ | 1–18 cu yd Capacity | Machine Size 6 – 44 Tons | For Wheel Loaders
DESCRIPTION
The TAG High Tip Roll Out Bucket series is expertly crafted to enhance dump height, release speed, and material shedding efficiency for wheel loaders working in tight-clearance or high-volume environments. With its rugged twin-cylinder sub-frame, these buckets maintain tipping control even under maximum load stress and elevated extensions.
Each unit is tailored for wheel loaders ranging from 12,000 to 88,000 lbs, allowing operations from compact utility machines to high-capacity production loaders. Ideal for agriculture, waste handling, material transfer stations, and stockpiling, this series boosts productivity where every inch of dump height matters. Requires 3rd function hydraulics for tipping actuation.
Key Feature
- Twin Cylinder Frame for High Tip Control Wide base keeps tipping stable with minimal flex or twist.
- Mechanical Dump Stops Increases operational reliability during fast load cycles.
- Low Volume Cylinder Housing Preserves internal space for higher fill capacity per scoop.
- Open-Side Cylinder Casings Minimizes carryback and debris buildup, especially with sticky materials.
- Coupler-Compatible Design Fits TAG Mechanical & Hydraulic Quick Couplers; adaptable to common OEM interfaces.
- Machine Fit Range: 12,000–88,000 lb Loader Class Serves utility compact loaders through full-size quarry machines.
- Requires Auxiliary Hydraulic Line Third-function hydraulics needed to power roll-out dumping motion.
Detailed Specifications
| Capacity (CU YD) | Width (in) | Part # | Weight (lbs) | Loader Size (lbs) |
|---|---|---|---|---|
| 1.0 | 92″ | P100RO – QC100RO | 1575 | 12,000–18,000 |
| 1.25 | 92″ | P125RO – QC125RO | 1650 | 15,000–20,000 |
| 1.5 | 96″ | P150RO – QC150RO | 1725 | 18,000–22,000 |
| 2.0 | 100″ | P200RO – QC200RO | 1800 | 20,000–28,000 |
| 2.5 | 100″ | P250RO – QC250RO | 1900 | 24,000–30,000 |
| 3.0 | 106″ | P300RO – QC300RO | 3400 | 26,000–34,000 |
| 3.5 | 106″ | P350RO – QC350RO | 3550 | 28,000–36,000 |
| 4.0 | 106″ | P400RO – QC400RO | 4100 | 30,000–38,000 |
| 5.0 | 106″ | P500RO – QC500RO | 5100 | 34,000–42,000 |
| 5.5 | 106″ | P550RO – QC550RO | 5350 | 36,000–44,000 |
| 6.0 | 120″ | P600RO – QC600RO | 5500 | 38,000–48,000 |
| 6.5 | 120″ | P650RO – QC650RO | 5600 | 40,000–50,000 |
| 7.0 | 120″ | P700RO – QC700RO | 5800 | 42,000–52,000 |
| 7.5 | 120″ | P750RO – QC750RO | 6000 | 44,000–55,000 |
| 8.0 | 129″ | P800RO – QC800RO | 6250 | 48,000–58,000 |
| 8.5 | 129″ | P850RO – QC850RO | 6450 | 50,000–60,000 |
| 9.0 | 129″ | P900RO – QC900RO | 6800 | 52,000–62,000 |
| 9.5 | 129″ | P950RO – QC950RO | 6950 | 55,000–64,000 |
| 10.0 | 134″ | P1000RO – QC1000RO | 7100 | 58,000–66,000 |
| 11.0 | 134″ | P1100RO – QC1100RO | 7500 | 60,000–70,000 |
| 12.0 | 134″ | P1200RO – QC1200RO | 7950 | 62,000–74,000 |
| 13.0 | 134″ | P1300RO – QC1300RO | 8400 | 65,000–76,000 |
| 14.0 | 134″ | P1400RO – QC1400RO | 8900 | 68,000–78,000 |
| 16.0 | 144″ | P1600RO – QC1600RO | 10050 | 72,000–82,000 |
| 17.0 | 144″ | P1700RO – QC1700RO | 10650 | 75,000–85,000 |
| 18.0 | 144″ | P1800RO – QC1800RO | 11275 | 78,000–88,000 |
