TAG Log & Lumber Forks Class 600 | Carriage Width 106″ | 60″–84″ Tine Length | Capacity 51,700 lbs | Machine Size 25-32.5 Tons | For Wheel Loaders
DESCRIPTION
The TAG Log & Lumber Forks for Class 600 wheel loaders deliver robust timber handling power with structural integrity built for demanding lumber yard environments. Designed for machines in the 22–30 ton range, each unit features a boxed steel carriage with full-length gussets, paired with rod-mounted tines that can be configured as either fixed rods or 5.00″ oscillating rods to improve load adaptability. The fork carriage supports adjustable tine positions using split collar lock collars, enabling operators to reposition forks safely without rod damage. With optional tall back stops, this model provides excellent vertical containment for bulky loads. Whether operating in tight log decks or wide yard staging areas, TAG’s forks ensure long-term performance and handling confidence.
Key Feature
- Heavy-Duty Boxed Carriage Frame Reinforced with gussets for structural strength and high-load resistance.
- Rod-Mounted Tines Available with fixed or 5.00″ oscillating rods to accommodate varied terrain and uneven loads.
- Split Collar Lock Collars Support tine repositioning while preventing damage to the rod assembly.
- Optional Extra-Height Back Stops Enhance vertical containment for long or stacked timber bundles.
- No Clamp Required Standard forks operate without hydraulic clamping—ideal for general-purpose log handling.
- Mount Options Available in both Pin-On and Quick Coupler formats to suit multiple machine setups.
Detailed Specifications
| SKU # | Tine Size | Weight (lbs) |
|---|---|---|
| P600LF10660 | 3.5″ x 8″ x 60″ | 2,860 |
| P600LFO10660 | 3.5″ x 8″ x 60″ | 2,860 |
| P600LF10672 | 3.5″ x 8″ x 72″ | 3,060 |
| P600LFO10672 | 3.5″ x 8″ x 72″ | 3,060 |
| P600LF10684 | 3.5″ x 8″ x 84″ | 3,260 |
| P600LFO10684 | 3.5″ x 8″ x 84″ | 3,260 |
| QC600LF10660 | 3.5″ x 8″ x 60″ | 2,860 |
| QC600LFO10660 | 3.5″ x 8″ x 60″ | 2,860 |
| QC600LF10672 | 3.5″ x 8″ x 72″ | 3,060 |
| QC600LFO10672 | 3.5″ x 8″ x 72″ | 3,060 |
| QC600LF10684 | 3.5″ x 8″ x 84″ | 3,260 |
| QC600LFO10684 | 3.5″ x 8″ x 84″ | 3,260 |
